KE KELIT  Art.Nr: 15472778182987

KE KELIT KM636S KELOX FB Hook and Loop Roll 30/2 6.5kN – 6060530

Regular price
Regular price € 13,58 inkl. USt.
€ 11,32 exkl. USt.
Verfügbarkeit wird geladen …
WhatsApp Sofortberatung Jetzt online Persönliche Beratung direkt vom Fachmann – Antwort meist in wenigen Minuten.

Expanded polystyrene according to ÖNORM B 6000, free of HFCs and CFCs, velour fabric lamination with PE coating, including adhesive overlap edge, for fixing KELOX-ULTRAX FB hook-and-loop pipes and ULTRA PE-RT hook-and-loop pipes without additional fastening. Thickness: 30mm Load capacity: max. 6.5 kN/m2 - EPS-T 650 - Dynamic stiffness < 20 MN/m3 Load capacity: max. 10 kN/m2 - EPS-T 1000 - Dynamic stiffness < 25 MN/m3 Impact sound improvement rating according to ÖNORM B 8115-4 with screed mass of 100 kg/m2: 30/2 - 6.5kN - Impact sound improvement rating: 28 dB - Lambda value: 0.040 W/mK 30/2 - 10kN - Impact sound improvement rating: 27 dB - Lambda value: 0.038 W/mK Water vapor diffusion resistance factor: 250,000 My Roll goods: 10x1m CAUTION: Protect from direct sunlight, do not store outdoors! Storage temperature max. 40°C!

Installation anfragen
Montage • Elektro • Inbetriebnahme
Wir bieten die Installation deiner Photovoltaikanlage durch unser Team sowie durch ausgewählte Partnerbetriebe an. Gemeinsam sorgen wir für eine fachgerechte Montage, Elektroinstallation und zuverlässige Inbetriebnahme.
Installation anfragen
Datenblatt
Hinweis: Der Link kann je nach Hersteller direkt einen Download starten.
Öffnen / Download

Technische Parameter

Produkteigenschaften ETIM

Ursprungsland
AT
Zolltarifnummer
39211390
eClass
22410105
eClass Bezeichnung
Lüftungsgerät ohne Wärmerückgewinnung
Serien
KELOX Flächenheizung
ETIM-Klasse
Systemplatte Flächenheizung
Werkstoff
Polystyrol (PS)
Noppenplatte
Nein
Tackerplatte
Nein
Einlegeplatte
Nein
Mit Folie
Ja
Isolierstärke
30 mm
Wärmeleitfähigkeit nach EN 12664
0.04 W/(m.K)
Max. Belastung
6.5 kN/m²
Geräuschdämmung
28 dB(A)
Dynamische Steifigkeit nach EN 29052-1
20 N/m²
Breite
1000 mm
Geeignet für Rohrdurchmesser
16 - 20 mm
