GRUNDFOS Grundfos Circulating Pump UPS 25-60 N 180mm 1x230V G1_1/2 – 96913085

Circulation pump Type: UPS 25-60 N 180 Circulation pump with 1-phase wet-rotor motor, power adjustment by 3 speed steps, speed steps selectable via step switch, external motor protection required Pump and motor form a unit, i.e. maintenance-free bearing lubrication by the pumped medium, shaft sealing not required. The pump has the following characteristics: - Radial bearings made of ceramic - Axial bearings made of carbon - Bearing plate and rotor can made of stainless steel - Corrosion-resistant impeller, composite material - Pump housing made of stainless steel The pump is equipped with a 1-phase motor. This does not require any additional, external motor protection. Pumped liquid: Pumped liquid: Water Medium temperature range: 2 .. 110 Celsius Medium temp. at data acquisition: 60 Celsius Density: 983.2 kg/m3 Technical data: Rated flow: 1.91 m3/h Rated head: 3.1 m Temperature class: 110 Approvals: CE,VDE,EAC,WEEE,RCM Materials: Pump housing: Stainless steel Pump casing: EN 1.4308 Impeller material: Composite material Impeller: PES+30% GF Installation: Ambient temperature: 0 .. 40 Celsius Max. ambient temp. at 80 Celsius medium temp.: 40 Celsius Max. operating pressure: 10 bar Pipe connection standard: ISO 228-1 Connection type: G Connection size: 1 1/2 inch Nominal pressure rating: PN 10 Installation length: 180 mm Electrical data: Power consumption P1 at speed level 1: 50 W Power consumption P1 at speed level 2: 55 W Power consumption P1 at speed level 3: 60 W Mains frequency: 50 Hz Rated voltage: 1 x 230 V Current at speed level 1: 0.21 A Current at speed level 2: 0.25 A Current consumption speed level 3: 0.28 A Operating capacitor size: 2.5 µF Protection class (according to IEC 34-5): IP44 Insulation class (IEC 85): F Ex-protection standard: no motor protection Other: Terminal box position: 9H Net weight: 2.86 kg Gross weight: 2.97 kg Shipping volume: 0.004 m3 Danish VVS no.: 380481061 Swedish RSK no.: 5803097 Finnish LVI no.: 4615616 Country of origin: RS Customs tariff no.: 84137030
