GEBERIT PE Branch 88.5 Degrees d 56/50 only for downpipes – 363.162.16.1

Geberit PE Branch 88.5°Application areasFor building drainageFor property drainageTechnical propertiesMaterial: PE-HDShape: Branchd, ø / outside diameter (mm): 56 mmd1, ø / outside diameter (mm): 50 mmarc / angle (°): 88.5 °H / height (cm): 17.5 cmX1 / leg length / L-dimension (cm): 10.5 cmX2 / leg length / L-dimension (cm): 7 cmX3 / leg length / L-dimension (cm): 7 cmK1 / shortening (cm) - max.: 7 cmK2 / shortening (cm) - max.: 3 cmK3 / shortening (cm) - max.: 3.5 cm
